Fisher XLT-30 Liquid Leak Detector - Option B - Multi-sensor Microphone

XLT-30 Liquid Leak Detector

Fisher XLT-30 Liquid Leak Detector - Option B - Multi-sensor Microphone

Fishers XLT-30 takes leak detection to a new level. Ultra sensitive sound microphones, combined with a non-distortion amplification system and crystal clear audio headphones make the XLT-30 the leak detector destined to set new standards for the leak professional.

Fisher’s XLT-30 leak detector is built to perform and priced to compete. With advanced electronic amplification and filtering, a tactile keypad, an easy to read digital display and notch feature (which allows independent suppression of outside interfering noise) the XLT-30 proves its worth again and again.

The XLT-30 has 4 Filtering Modes and Noise Rejection Filter, available in all modes. ALL allows you to listen without any filters (60 Hz to 6 kHz), LO target the Lower Frequencies (great for PVC Pipe), HI Higher Frequencies, or FC Frequency Choice - where you select what range to want listen to.

STANDARD EQUIPMENT:

• Heavy-Duty Carrying Case
• Probe Cable Assembly
• Operation Manual
• Control Unit
• Head Phones
• Multi-Sensor
• Carry Strap
• Housing Bracket
• Sound Rods
• WEIGHT: (4.5 kg)

SPECIFICATIONS

• Operating Frequency:
• 60 Hz – 6 kHz, Gain = 95 db
• 20 Hz – 60 Hz, Gain > 90 dB
• Filter Types and Frequency Ranges: All Pass: 60 Hz to 6 kHz
• Low Pass: Adjustable cut-off frequency from 150 Hz to 2.4 kHz
• High Pass: Adjustable pass band frequency from 150 Hz to 2.4 kHz
• Band Pass: Adjustable center frequency from 150 Hz to 2.4 kHz
• Notch Filter: Adjustable center frequency rejection from 150 Hz to 2.4 kHz
• Can be used simultaneously with any filter option
• Output Indications:
• Audio: High performance headphones (64 ohms)
• Visual: LCD bar graph and 2-digit numeric display
• Grade of Protection: Splash Proof
• Battery Test: Automatic
• Battery Quantity/Type: 2 / 9V Alkaline
• Battery Life: 50 Hours (approximately)
