Fisher XLT-17 Liquid Leak Detector

Fisher’s XLT-17 is a liquid leak detector that finds leaks in four easy steps: by electronically amplifying leak sounds, selectively filtering out noise, isolating the leak sound, and leading the operator to the source of the leak.

FEATURES

• Detects and pinpoints liquid leaks in pipes
• 4 Frequency Filters: Low Pass, High Pass, Band Pass and All Pass
• Last setting memory feature
• Touch-control keypad
• Shielded sensor for reduced response to outside noise
• Improved headset for clearer sound response
• Automatic battery test – real time voltage level
• Operates on two 9 volt batteries
• Compact control box that can be worn around the neck or over the shoulder with an attachable strap
• Heavy duty carrying case

 SPECIFICATIONS

• Operating Frequency:
• 60 Hz – 6 kHz, Gain = 95 db
• 20 Hz – 60 Hz, Gain > 90 dB
• Filter Types and Frequency Ranges: All Pass: 60 Hz to 6 kHz
• Low Pass: Adjustable cut-off frequency from 150 Hz to 2.4 kHz
• High Pass: Adjustable pass band frequency from 150 Hz to 2.4 kHz
• Band Pass: Adjustable center frequency from 150 Hz to 2.4 kHz
• Notch Filter: Adjustable center frequency rejection from 150 Hz to 2.4 kHz
• Can be used simultaneously with any filter option
• Output Indications:
• Audio: High performance headphones (64 ohms)
• Visual: LCD bar graph and 2-digit numeric display
• Grade of Protection: Splash Proof
• Battery Test: Automatic
• Battery Quantity/Type: 2 / 9V Alkaline
• Battery Life: 50 Hours (approximately)
